Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – Multiple Lengths
The Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – Multiple Lengths is a high-performance simplex fibre patchcord designed for reliable optical connectivity across FTTH networks, telecom racks and internal building installations.
Manufactured using G.657A2 bend-insensitive singlemode fibre, this patchcord enables tight bend radius routing with minimal signal loss, making it ideal for confined spaces such as cabinets, patch panels and wall outlets. The LC/APC to SC/APC connector configuration provides flexible connectivity between different interface types while maintaining excellent return loss and signal stability.
The Ø3mm LSZH (Low Smoke Zero Halogen) outer sheath offers enhanced mechanical protection while maintaining flexibility for easy installation. Its white finish is ideal for residential and visible installations where a clean, discreet appearance is required.
Engineered with precision zirconia ceramic ferrules, the patchcord ensures accurate alignment, low insertion loss and consistent long-term performance across fibre networks.
Key Features:
-
LC/APC to SC/APC connectors for mixed interface connectivity
-
G.657A2 bend-insensitive singlemode fibre
-
Simplex (SX) configuration
-
Available in multiple lengths (e.g. 1m, 2m, 3m, 5m, 10m and more)
-
Ø3.0mm LSZH sheath for durability and flexibility
-
White outer jacket for clean, aesthetic installations
-
Low insertion loss and high return loss performance
-
Zirconia ceramic ferrules for precision alignment
-
Fully tested to IEC standards
Technical Specifications:
-
Product Type: Fibre patchcord (simplex)
-
Connector Type: LC/APC – SC/APC
-
Fibre Type: Singlemode G.657A2
-
Configuration: Simplex (SX)
-
Length Options: Multiple lengths available
-
Cable Diameter: Ø3.0 mm
-
Sheath Material: LSZH (Low Smoke Zero Halogen)
-
Colour: White
-
Insertion Loss: ≤ 0.25 dB max, ≤ 0.12 dB typical (Grade B)
-
Return Loss: ≥ 60 dB (APC connectors)
-
Operating Temperature: -40°C to +75°C
-
Static Bend Radius: 15 mm
-
Crush Resistance: 1000 N
-
Compliance: IEC 61300, IEC 61754
Applications:
-
FTTH (Fibre to the Home) installations
-
Telecom cabinets and patch panels
-
Cross-connection between LC and SC interfaces
-
Internal fibre links and structured cabling
-
Data and broadband infrastructure
