Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – 2m

Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – 2m

The Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – 2m is a high-performance simplex fibre patchcord designed for reliable optical connectivity between different connector interfaces in FTTH networks, telecom racks and internal building installations.

Manufactured using G.657A2 bend-insensitive singlemode fibre, this patchcord enables tight bend radius installation with minimal signal loss, making it ideal for confined spaces such as cabinets, patch panels and wall outlets. The LC/APC to SC/APC connector configuration provides flexible connectivity between equipment and infrastructure with different port types, while ensuring excellent return loss and signal stability.

The Ø3mm LSZH (Low Smoke Zero Halogen) outer sheath delivers enhanced mechanical protection while maintaining flexibility for easy routing. Its white finish is well suited for residential and visible installations where a clean, discreet appearance is required.

Designed with precision zirconia ceramic ferrules, the patchcord ensures accurate alignment, low insertion loss and consistent long-term performance across demanding fibre networks.

Key Features:

• LC/APC to SC/APC connectors for mixed interface connections

• G.657A2 bend-insensitive singlemode fibre

• Simplex (SX) configuration

• 2 metre length

• Ø3.0mm LSZH sheath for durability and flexibility

• White outer jacket for clean, aesthetic installations

• Low insertion loss and high return loss performance

• Zirconia ceramic ferrules for precision alignment

• Fully tested to IEC standards

Technical Specifications:

• Product Type: Fibre patchcord (simplex)

• Connector Type: LC/APC – SC/APC

• Fibre Type: Singlemode G.657A2

• Configuration: Simplex (SX)

• Length: 2 m

• Cable Diameter: Ø3.0 mm

• Sheath Material: LSZH (Low Smoke Zero Halogen)

• Colour: White

• Insertion Loss: ≤ 0.25 dB max, ≤ 0.12 dB typical (Grade B)

• Return Loss: ≥ 60 dB (APC connectors)

• Operating Temperature: -40°C to +75°C

• Static Bend Radius: 15 mm

• Crush Resistance: 1000 N

• Compliance: IEC 61300, IEC 61754

Applications:

• FTTH (Fibre to the Home) installations

• Telecom cabinets and patch panels

• Cross-connection between LC and SC interfaces

• Optical outlets and internal fibre links

• Data and broadband infrastructure
