Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – 1m

Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – 1m

The Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – 1m is a compact, high-performance simplex fibre patchcord designed for short-distance optical connections in FTTH networks, telecom racks and internal building installations.

Manufactured using G.657A2 bend-insensitive singlemode fibre, this patchcord supports tight bend radius routing with minimal signal loss, making it ideal for confined spaces such as cabinets, patch panels and wall outlets. The LC/APC to SC/APC connector configuration provides flexible connectivity between different interface types while maintaining excellent return loss and signal stability.

The Ø3mm LSZH (Low Smoke Zero Halogen) outer sheath offers strong mechanical protection while remaining flexible for easy installation. Its white finish is well suited for residential and visible installations where a clean, discreet appearance is required.

Engineered with precision zirconia ceramic ferrules, the patchcord ensures accurate alignment, low insertion loss and consistent long-term performance across fibre networks.

Key Features:

• LC/APC to SC/APC connectors for mixed interface connectivity

• G.657A2 bend-insensitive singlemode fibre

• Simplex (SX) configuration

• 1 metre length for short connections

• Ø3.0mm LSZH sheath for durability and flexibility

• White outer jacket for clean, aesthetic installations

• Low insertion loss and high return loss

• Zirconia ceramic ferrules for precision alignment

• Fully tested to IEC standards

Technical Specifications:

• Product Type: Fibre patchcord (simplex)

• Connector Type: LC/APC – SC/APC

• Fibre Type: Singlemode G.657A2

• Configuration: Simplex (SX)

• Length: 1 m

• Cable Diameter: Ø3.0 mm

• Sheath Material: LSZH (Low Smoke Zero Halogen)

• Colour: White

• Insertion Loss: ≤ 0.25 dB max, ≤ 0.12 dB typical (Grade B)

• Return Loss: ≥ 60 dB (APC connectors)

• Operating Temperature: -40°C to +75°C

• Static Bend Radius: 15 mm

• Crush Resistance: 1000 N

• Compliance: IEC 61300, IEC 61754

Applications:

• FTTH (Fibre to the Home) installations

• Telecom cabinets and patch panels

• Cross-connection between LC and SC interfaces

• Optical outlets and short internal links

• Data and broadband infrastructure
