Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – 10m

SX LC/APC–SC/APC Patchcord.

Length (m): 10

Description

Description:

Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – 10m



The Telenco Patchcord White SX LC/APC–SC/APC G.657A2 Ø3mm – 10m is a high-performance simplex fibre patchcord designed for reliable optical connectivity across FTTH networks, telecom racks and internal building installations.



Manufactured using G.657A2 bend-insensitive singlemode fibre, this patchcord supports tight bend radius routing with minimal signal loss, making it ideal for structured cabling within cabinets, patch panels and wall outlets. The LC/APC to SC/APC connector configuration enables seamless connection between different interface types while maintaining excellent return loss and signal stability.



The Ø3mm LSZH (Low Smoke Zero Halogen) outer sheath provides strong mechanical protection while remaining flexible for easy installation. Its white finish is ideal for residential and visible deployments where a clean and discreet appearance is required.



Built with precision zirconia ceramic ferrules, the patchcord ensures accurate alignment, low insertion loss and consistent long-term performance across fibre networks.

Key Features:

  • LC/APC to SC/APC connectors for mixed interface connectivity

  • G.657A2 bend-insensitive singlemode fibre

  • Simplex (SX) configuration

  • 10 metre length

  • Ø3.0mm LSZH sheath for durability and flexibility

  • White outer jacket for clean, aesthetic installations

  • Low insertion loss and high return loss performance

  • Zirconia ceramic ferrules for precision alignment

  • Fully tested to IEC standards

Technical Specifications:

  • Product Type: Fibre patchcord (simplex)

  • Connector Type: LC/APC – SC/APC

  • Fibre Type: Singlemode G.657A2

  • Configuration: Simplex (SX)

  • Length: 10 m

  • Cable Diameter: Ø3.0 mm

  • Sheath Material: LSZH (Low Smoke Zero Halogen)

  • Colour: White

  • Insertion Loss: ≤ 0.25 dB max, ≤ 0.12 dB typical (Grade B)

  • Return Loss: ≥ 60 dB (APC connectors)

  • Operating Temperature: -40°C to +75°C

  • Static Bend Radius: 15 mm

  • Crush Resistance: 1000 N

  • Compliance: IEC 61300, IEC 61754

Applications:

  • FTTH (Fibre to the Home) installations

  • Telecom cabinets and patch panels

  • Cross-connection between LC and SC interfaces

  • Internal fibre links and structured cabling

  • Data and broadband infrastructure
