Int/Ext Midspan Cable G657B3 3.0mm Cca – White – Multiple Fibre Counts

Internal / External Midspan Cable G657B3 3.0mm Cca – White – Multiple Fibre Counts

The Internal / External Midspan Cable G657B3 3.0mm Cca – White – Multiple Fibre Counts is a compact, high-performance fibre solution designed for scalable and discreet deployment in MDU, residential and access network environments.

Available in multiple fibre counts (including 12F and 24F variants), this cable range offers flexibility for both standard and higher-density installations. Its white FR-LSZH outer sheath is ideal for internal visible routing, delivering a clean, aesthetic finish while maintaining compliance with fire safety requirements.

Engineered with water-blocking aramid yarn strength members, the cable is suitable for both indoor and outdoor installations, ensuring durability and long-term reliability. The 3.0mm compact diameter allows easy handling and discreet installation along walls, ceilings and corridors.

Utilising G.657B3 bend-insensitive fibre, the cable supports tight bend radii with minimal signal loss, making it ideal for complex routing paths and midspan access applications in multi-dwelling environments.

Key Features:

• Available in multiple fibre counts (12F and 24F options)

• Suitable for internal and external installations

• White sheath for discreet, aesthetic indoor routing

• G.657B3 bend-insensitive fibre for tight routing

• Compact 3.0mm diameter for easy installation

• FR-LSZH outer sheath for enhanced fire safety

• Water-blocking aramid yarn strength members

• Designed for midspan access and corridor deployments

• Compliant with CPR Cca fire rating

Technical Specifications:

• Product Type: Fibre optic corridor / midspan cable

• Fibre Options: 12F / 24F

• Fibre Type: ITU-T G.657B3 singlemode

• Outer Diameter: 3.0 ± 0.1 mm

• Sheath Material: FR-LSZH (Low Smoke Zero Halogen)

• Colour: White

• Strength Member: Aramid yarns

• Fire Rating: CPR Cca compliant

Mechanical & Environmental Performance:

• Tensile Strength: 200N (long-term) / 500N (short-term)

• Minimum Bend Radius:

  • Dynamic: 30D

  • Static: 15D

• Crush Resistance: 200N/10cm (long-term), 500N/10cm (short-term)

• Installation Temperature: -10°C to +65°C

• Operating Temperature: -40°C to +70°C

Applications:

• MDU corridor and riser installations

• Internal visible fibre routing

• FTTH and FTTx deployments

• Midspan cable access and distribution networks

• Residential and commercial fibre infrastructure
