Rainford Three Section Colocation Rack Cabinet – 42U × 800 × 1200
The Rainford SafeServ® CX 42U Three Section Colocation Rack Cabinet is a premium, UK-engineered multi-tenant enclosure designed for secure, segregated hosting in high-performance data centres. With three fully isolated compartments, each with independent access, airflow and cable routing, this cabinet provides outstanding security and separation for colocation, MSP, and hosting environments.
With a 42U height, 800mm width, and 1200mm depth, the rack is constructed from high-strength steel and finished in a durable RAL 9003 polyester powder coat. It features 83% airflow mesh doors, depth-adjustable 19” mounting profiles and segregated cable pathways to ensure optimal cooling, clean cable management and flexible deployment of servers, switches and networking equipment.
Key Features:
-
Three fully isolated colocation compartments for secure multi-tenant environments
-
High-performance 83% airflow mesh front (single-leaf) and rear (double-leaf) doors
-
Individual 3-pin combination swing handles with single-point locking
-
Depth-adjustable 19” mounting profiles (front & rear) in every compartment
-
Plain, horizontally split side panels for easy installation and maintenance
-
Segregated top and base cable entry for structured cable management per tenant
-
Rigid UK-manufactured steel frame for lasting durability
-
RAL 9003 powder-coated finish for a clean data-centre aesthetic
-
Supplied with baying kit and levelling feet
Technical Specifications:
-
Height: 42U
-
Width: 800mm
-
Depth: 1200mm
-
Sections / Compartments: 2 x 13U + 1 x 14U
-
Material: Steel
-
Colour: RAL 9003 (white)
-
Finish: Polyester powder coat
-
Mounting Format: 19-inch
-
Mounting Profiles: Front & rear, depth adjustable
-
Profile Setback: 120mm front / 120mm rear
-
Front Door: Single-leaf, 83% airflow mesh
-
Rear Doors: Double-leaf, 83% airflow mesh
-
Locks: 3-pin combination swing handles with single-point locking
-
Side Panels: Plain, horizontally split, cam-latched
-
Cable Routing: Segregated top and bottom entry channels
-
Earthing: Base-mounted copper earth bar
-
Compliance:
-
IEC 60297-3
-
EIA-310-E
-
RoHS
-
REACH
-
ISO9001:2015
