Rainford Three Section Colocation Rack Cabinet – 47U × 800 × 1200
The Rainford SafeServ® CX 47U Three Section Colocation Rack Cabinet is a premium, multi-compartment enclosure engineered for secure, high-density hosting within shared data-centre environments. Manufactured in the UK, this cabinet provides three fully isolated compartments, delivering independent access, airflow separation and cable routing—ideal for colocation, MSPs, hosting providers and multi-tenant facilities.
With a 47U total height, 800mm width, and 1200mm depth, the rack is constructed from heavy-duty steel and finished in RAL 9003 polyester powder coat. Each compartment includes its own 19” mounting profiles, access control and segregated cable pathways. High-airflow 83% mesh doors, combined with adjustable mounting depths, ensure excellent thermal performance for modern IT and network equipment.
Key Features:
-
Three fully isolated colocation compartments for multi-tenant hosting
-
83% airflow mesh doors (front single-leaf, rear double-leaf)
-
Individually controlled 3-pin combination swing handles with single-point locking
-
19” mounting profiles (front and rear) in each compartment
-
Horizontally split side panels for easy equipment access
-
Segregated top & base cable entry for controlled routing per compartment
-
Rigid, UK-manufactured steel frame for exceptional strength
-
Durable RAL 9003 powder-coated finish
-
Supplied with baying kit and levelling feet
Technical Specifications:
-
Total Height: 47U
-
Width: 800mm
-
Depth: 1200mm
-
Sections / Compartments: 3 x 15U
-
Material: Steel
-
Finish: Polyester powder coat
-
Colour: RAL 9003 (white)
-
Front Door: Single-leaf 83% airflow mesh
-
Rear Doors: Double-leaf 83% airflow mesh
-
Door Locks: 3-pin combination swing handles, single-point locking
-
Side Panels: Plain, horizontally split with cam-latch
-
Mounting Format: 19-inch
-
Mounting Profiles: Front & rear, fully depth adjustable
-
Profile Setback: 120mm (front & rear)
-
Cable Routing: Segregated top and base entry channels
-
Earthing: Base-mounted copper earth bar
-
