Rainford Four Section Colocation Rack Cabinet – 42U × 800 × 1000
The Rainford SafeServ® CX 42U Four Section Colocation Rack Cabinet is a fully segregated, UK-engineered enclosure designed for multi-tenant and colocation data-centre environments. With four independently isolated compartments, each with its own locking, airflow path and cable routing, this cabinet provides maximum security and physical separation for MSPs, hosting providers and shared enterprise facilities.
Built with a 42U height, 800mm width, and 1000mm depth, the cabinet combines robust steel construction with a durable RAL 9003 polyester powder-coat finish. High-performance 83% airflow mesh doors, depth-adjustable 19” mounting profiles and segregated cable entry channels ensure excellent cooling efficiency and structured installation for high-density IT and networking equipment.
Key Features:
-
Four fully isolated compartments for complete multi-tenant separation
-
83% airflow mesh front (single-leaf) and rear (double-leaf) doors
-
Individual 3-pin combination swing handles with single-point locking
-
Front and rear 19” depth-adjustable mounting profiles in each compartment
-
Plain, horizontally split side panels for accessible installation and maintenance
-
Segregated top and base cable entry for clean, controlled routing per compartment
-
Rigid UK-manufactured steel frame for exceptional durability
-
High-quality RAL 9003 powder-coated finish
-
Includes baying kit and levelling feet for seamless row deployment
Technical Specifications:
-
Height: 42U
-
Width: 800mm
-
Depth: 1000mm
-
Sections / Compartments: 2 x 10U + 2 x 9U
-
Material: Steel
-
Finish: Polyester powder coat
-
Colour: RAL 9003 (white)
-
Mounting Format: 19"
-
Mounting Profiles: Front & rear, fully depth adjustable
-
Profile Setback: 120mm (front & rear)
-
Front Door: Single-leaf, 83% airflow mesh
-
Rear Doors: Double-leaf, 83% airflow mesh
-
Locking: 3-pin combination swing handles, single-point locking
-
Side Panels: Plain, horizontally split, cam-latched
-
Cable Routing: Independent top & bottom cable entry channels
-
Earthing: Base-mounted copper earth bar
-
Compliance:
-
IEC 60297-3
-
EIA-310-E
-
RoHS
-
REACH
-
ISO9001:2015
