Rainford Four Section Colocation Rack Cabinet – 47U × 800 × 1200
The Rainford SafeServ® CX 47U Four Section Colocation Rack Cabinet is a high-security, UK-manufactured multi-tenant enclosure designed for environments requiring maximum compartmentalisation and tenant separation. With four fully isolated compartments, each with its own locking, airflow path and cable routing, this cabinet delivers exceptional security and operational independence for colocation data centres, MSP hosting environments and shared IT facilities.
The cabinet’s 47U height, 800mm width and 1200mm depth provide generous rack space while maintaining strict physical segregation. Built from heavy-gauge steel and finished in durable RAL 9003 polyester powder coat, the SafeServ® CX range combines structural strength with premium airflow capability, thanks to its 83% perforated mesh doors and depth-adjustable 19” mounting profiles.
Ideal for high-density installations where multiple customers must share a single footprint without compromising access control or thermal performance.
Key Features:
-
Four fully isolated colocation compartments for maximum tenant separation
-
High-airflow 83% perforated mesh front (single-leaf) and rear (double-leaf) doors
-
Individual 3-pin combination swing handles with single-point locking per compartment
-
Front and rear 19” mounting profiles, fully depth adjustable
-
Plain, horizontally split side panels for easy installation and service access
-
Segregated top and base cable entry routes ensuring clean, independent cable pathways
-
Rigid, UK-engineered steel frame for superior stability
-
High-quality RAL 9003 powder-coated finish
-
Supplied with baying kit and levelling feet for seamless row deployment
Technical Specifications:
-
Height: 47U
-
Width: 800mm
-
Depth: 1200mm
-
Sections / Compartments: 4 x 11U
-
Material: Steel
-
Finish: Polyester powder coat
-
Colour: RAL 9003 (white)
-
Front Door: Single-leaf, 83% airflow mesh
-
Rear Doors: Double-leaf, 83% airflow mesh
-
Locking: 3-pin combination swing handles, single-point locking
-
Side Panels: Plain, horizontally split with cam-latch
-
Mounting Format: 19-inch
-
Profiles: Front & rear, depth adjustable
-
Profile Setback: 120mm (front & rear)
-
Cable Routing: Segregated top and bottom cable entry channels
-
Earthing: Base-mounted horizontal copper earth bar
-
