Rainford Four Section Colocation Rack Cabinet – 47U × 800 × 1000
The Rainford SafeServ® CX 47U Four Section Colocation Rack Cabinet is a UK-engineered, high-security enclosure designed for maximum compartmentalisation in multi-tenant data-centre environments. Featuring four fully isolated compartments, each with independent access, airflow and cable routing, this cabinet provides the highest level of tenant separation—ideal for colocation facilities, MSPs, hosting providers and shared IT spaces.
With a 47U height, 800mm width, and 1000mm depth, this cabinet is built from heavy-gauge steel and finished in durable RAL 9003 polyester powder coat. High-density deployments benefit from 83% airflow mesh front and rear doors, adjustable 19” mounting rails and segregated cable management channels to maintain clean installation and optimal cooling performance.
Key Features:
-
Four fully isolated compartments for complete tenant separation
-
High-airflow 83% mesh single-leaf front and double-leaf rear doors
-
Individual 3-pin combination swing handles with single-point locking
-
Front and rear 19” mounting profiles (depth adjustable) in every compartment
-
Horizontally split plain side panels for easy installation and maintenance
-
Segregated top and base cable entry for controlled routing per section
-
Strong UK-manufactured steel frame for long-term reliability
-
Durable RAL 9003 powder-coated finish
-
Supplied with baying kit and levelling feet
Technical Specifications:
-
Height: 47U
-
Width: 800mm
-
Depth: 1000mm
-
Sections / Compartments: 4 x 11U
-
Material: Steel
-
Colour: RAL 9003 (white)
-
Finish: Polyester powder coat
-
Mounting Format: 19"
-
Mounting Profiles: Front & rear, depth adjustable
-
Profile Setback: 120mm (front & rear)
-
Front Door: Single-leaf 83% airflow mesh
-
Rear Doors: Double-leaf 83% airflow mesh
-
Locks: 3-pin combination swing handles, single-point locking
-
Side Panels: Plain, horizontally split, cam-latched
-
Cable Entry: Segregated top & bottom channels
-
Earthing: Base-mounted copper earth bar
-
Compliance:
-
IEC 60297-3
-
EIA-310-E
-
RoHS
-
REACH
-
ISO9001:2015
