UPTEC 19" Wall Mount Cabinet – 22U – 600 x 600mm – Removable Panels

UPTEC 19" Wall Mount Cabinet – 22U – 600 x 600mm – Removable Panels

The UPTEC 19" 22U Wall Mount Cabinet – 600 x 600mm is a professional network enclosure designed for the secure installation and organisation of standard 19-inch networking, fibre and communications equipment. Offering a generous 22U rack capacity within a wall-mounted format, it provides an efficient solution for network installations where available floor space needs to be maximised.

With overall dimensions of 600 x 600 x 1081mm, the cabinet provides substantial internal space for compatible switches, patch panels, fibre optic equipment and other 19-inch rack-mounted hardware. A maximum 60kg load capacity supports a wide range of professional networking and communications installations.

The cabinet incorporates four 19-inch uprights, providing standard mounting positions for compatible equipment. Removable side panels improve access during equipment installation, cable termination and ongoing maintenance, helping engineers work efficiently within the enclosure. Finished in professional RAL 9005 black and rated to IP20, the cabinet provides protection against solid objects greater than 12mm. A screw kit and earthing components are included, providing essential hardware for a professional installation.

Key Features:

• Professional UPTEC 22U wall-mounted network cabinet

• Standard 19-inch equipment mounting format

• 600 x 600 x 1081mm overall dimensions

• Maximum load capacity of 60kg

• Four 19-inch uprights for equipment installation

• Removable side panels for improved access

• Wall-mounted design helps maximise available floor space

• IP20 protection rating

• Screw kit and earthing components included

• Professional RAL 9005 black finish

Technical Specifications:

• Brand: UPTEC

• Product Type: Wall Mount Network Cabinet

• Rack Format: 19"

• Rack Capacity: 22U

• Dimensions: 600 x 600 x 1081mm

• Width: 600mm

• Depth: 600mm

• Height: 1081mm

• Maximum Load Capacity: 60kg

• Number of 19" Uprights: 4

• Side Panels: Removable

• IP Rating: IP20

• Protection: Solid objects greater than 12mm

• Colour: Black

• RAL Colour: RAL 9005

• Screw Kit: Included

• Earthing: Included

• Installation Type: Wall Mounted

Applications:

• Structured cabling installations

• Enterprise networks

• Telecom infrastructure

• Fibre optic installations

• Network switch installation

• Patch panel installation

• Communications rooms

• Network equipment housing

• Distributed network infrastructure

• Professional network installations
