Telenco Pivoting Patch Panel 19’’ 1U – 48FO SC/UPC G.657A2 R/L
The Telenco 48FO Pivoting Patch Panel is a compact, high-density fibre solution designed for efficient deployment in FTTH and optical access networks. Pre-terminated with 48 SC/UPC connectors and bend-insensitive G.657A2 fibre, this 1U panel ensures fast installation and long-term performance. Its pivoting tray provides configurable right- or left-hand opening, offering convenient front access for installation and maintenance. With a recessed front face and factory-assembled quality, it’s suitable for 19” racks, shallow-depth enclosures, and demanding telecom environments.
Key Features:
-
Pre-terminated with 48 x SC/UPC connectors and G.657A2 fibre
-
Pivoting tray with left/right opening for easy front access
-
Compact 1U height, compatible with standard 19” racks and street cabinets
-
Recessed front panel with cord protection and efficient cable routing
-
Bend-insensitive G.657A2 fibre supports tight routing without signal degradation
-
Supplied with splice sleeves, cage nuts, screws, and cable ties
-
Factory-tested and built in Europe for consistent performance
-
Complies with IEC-61300 optical and mechanical standards
Technical Specification:
-
Fibre Count: 48FO
-
Connector Type: SC/UPC
-
Fibre Type: G.657A2
-
Pigtail Length: 2.5m
-
Insertion Loss (IL): ≤ 0.12dB avg / ≤ 0.25dB max (97% samples)
-
Return Loss (RL): ≥ 50dB (UPC)
-
Material: Fibre-reinforced composite
-
Ferrule: Zirconia ceramic
-
Dimensions: 235+38mm (D) x 482mm (W) x 44mm (H)
-
Operating Temperature: –40°C to +75°C
-
Compliance: IEC-61300
