Visual Fault Locator 20mW (10+km) for SC/ST/FC

Visual Fault Locator is used for the measurement in single-mode or multi-mode fibres. It features a rugged design, a universal connector and accurate measurement.

Product code: Q5004-20MW
£43.20 exc VAT
 In stock
Request for quote




  • 2.5 mm universal adapter
  • Operates either in CW or Pulsed
  • Constant output power
  • Lower Battery warning
  • Long battery life(up to 60 hours)
  • Convenient for use and carry Dust-proof design keeps fibre connectors clean


Wavelength 650nm ± 20nm Output Power 20mW
Dynamic Distance 12-15km Housing Material Metal
Connector 2.5mm Universal connector Operation Mode Pulsed (2Hz) and CW
Operation Temperature -10 °C~ +50 °C, < 90%RH Storage Temperature -20~+70°C
Dimensions 210x73x30mm Weight 150g
Battery Type AA * 2 Battery Life up to 60 hours

Technical characteristics

  • Product model
  • Q5004-20MW
  • Product code
  • Q5004-20MW
  • MPN
  • 66806
