SWA Power Cable – 2 Core – 6mm - Per Metre

SWA Power Cable – 2 Core – 6mm – Per Metre

The SWA Power Cable – 2 Core – 6mm – Per Metre is a robust low voltage power cable designed for fixed wiring applications in power distribution networks, underground installations, outdoor environments, indoor installations and cable ducting.

Manufactured with Class 2 stranded copper conductors, XLPE insulation, PVC bedding, Steel Wire Armour (SWA) and a durable PVC outer sheath, this cable provides excellent mechanical protection and long-term reliability in demanding environments. The steel wire armour safeguards the cable against impact and mechanical damage, while the UV-resistant outer sheath ensures dependable performance in external installations.

Rated at 0.6/1kV, the cable is suitable for power and auxiliary applications requiring durable, flame-retardant construction. Supplied per metre, it allows installers to purchase the exact cable length required, reducing waste and simplifying installation. Every cable is BASEC approved and quality assured through The Cable Lab®, an ISO/IEC 17025 and IECEE CBTL accredited testing facility.

Key Features:

• 2 core 6mm² SWA power cable

• Sold per metre

• Class 2 stranded copper conductors

• XLPE insulated

• Steel Wire Armour (SWA) protection

• UV-resistant PVC outer sheath

• Suitable for underground and outdoor installation

• BASEC approved

• Flame retardant construction

• Suitable for fixed power installations

Technical Specifications

• Product Type: SWA Power Cable

• Number of Cores: 2

• Conductor Size: 6mm²

• Supply Length: Per Metre

• Conductor: Class 2 Stranded Copper

• Insulation: XLPE (Cross-Linked Polyethylene)

• Bedding: PVC (Polyvinyl Chloride)

• Armour: Steel Wire Armour (SWA)

• Outer Sheath: PVC (Polyvinyl Chloride)

Electrical Rating

• Voltage Rating (Uo/U): 0.6/1kV

Temperature Rating

• Fixed Installation: -25°C to +90°C

Minimum Bending Radius

• 6 × Overall Cable Diameter (1.5mm²–16mm²)

Third-Party Accreditation

• BASEC Approved

• Tested and Certified by BASEC

• Verified by The Cable Lab® (ISO/IEC 17025 & IECEE CBTL Accredited)

Standards

• BS 5467

• IEC/EN 60502-1

• IEC/EN 60228

• IEC/EN 60332-1-2 (Flame Retardant)

• UV Resistant

Applications:

• Power distribution

• Underground cable installations

• Outdoor power networks

• Indoor fixed wiring

• Cable ducting

• Industrial facilities

• Commercial buildings

• Utilities infrastructure

• Plant and machinery

• Auxiliary power circuits
