Jonard Tools CableSaber+™ Armoured Mid-Span Cable Slit & Ring Tool – 4-30mm – AST-210
The Jonard Tools CableSaber+™ AST-210 is a professional mid-span cable slitting and ringing tool designed for accessing armoured and thick-jacketed fibre optic cables with diameters ranging from 4mm to 30mm. Engineered for precision and durability, it provides a reliable solution for fibre optic cable preparation and telecommunications network installations.
Featuring an adjustable precision steel blade with a maximum cutting depth of 6.5mm, the CableSaber+™ enables controlled cutting through tough cable jackets and armouring while helping protect the internal optical fibres. The blade can be positioned longitudinally for cable slitting or radially for circumferential ringing, providing two cutting functions in one tool.
The integrated aluminium shaft provides stability during cutting, helping prevent unwanted spiralling and maintain a consistent cutting path. Its shaft housing also functions as an ergonomic handle, offering additional leverage and control when working with demanding cable constructions.
Designed for efficient field operation, the tool incorporates a hand-adjustable thumb screw for quick blade depth adjustments without additional tools. Its rugged anodised aluminium and steel construction ensures durability during regular use in telecommunications and fibre network installations. The CableSaber+™ is particularly suited to Corning Optical 144F to 1728F RocketRibbon® cables, making it a practical choice for engineers working with high-fibre-count optical cable infrastructure.
Key Features:
-
Designed for mid-span access to armoured and thick-jacketed cables
-
Suitable for cable diameters from 4mm to 30mm
-
Compatible with Corning Optical 144F–1728F RocketRibbon® cables
-
Adjustable blade depth up to 6.5mm
-
Precision steel blade for controlled cable jacket cutting
-
Longitudinal blade positioning for cable slitting
-
Radial blade positioning for circumferential ringing
-
Helps protect internal optical fibres during cable preparation
-
Aluminium shaft provides stability during cutting
-
Stable cutting action helps prevent blade spiralling
-
Shaft housing doubles as a handle for improved leverage
-
Thumb screw enables quick, tool-free blade depth adjustment
-
Rugged anodised aluminium and steel construction
-
Suitable for professional fibre optic installation and maintenance
Technical Specifications:
-
Brand: Jonard Tools
-
Product Range: CableSaber+™
-
Product Type: Mid-Span Cable Slit & Ring Tool
-
Manufacturer Part Number: AST-210
-
Cutting Functions: Longitudinal Slitting and Radial Ringing
-
Cable Compatibility: Armoured and Jacketed Cables
-
Minimum Cable Diameter: 4mm
-
Maximum Cable Diameter: 30mm
-
Maximum Blade Depth: 6.5mm
-
Blade Material: Steel
-
Body Construction: Anodised Aluminium and Steel
-
Blade Adjustment: Manual Thumb Screw
-
Length: 195.3mm
-
Width: 54mm
-
Height: 27.6mm
-
Product Weight: Approximately 341g
-
UPC: 810053352250
Applications:
-
Fibre optic cable mid-span access
-
Armoured fibre optic cable preparation
-
Thick-jacketed cable stripping
-
Longitudinal cable jacket slitting
-
Circumferential cable jacket ringing
-
High-fibre-count cable installations
-
Corning RocketRibbon® cable preparation
-
Telecommunications network installations
-
Fibre optic network maintenance
-
Fibre distribution and cable jointing
-
Outside plant (OSP) fibre installations
