UPTEC 19" Network Cabinet – 42U – 800 x 800mm – Perforated Front & Rear Doors – Black

UPTEC 19" Network Cabinet – 42U – 800 x 800mm – Perforated Front & Rear Doors – Black

The UPTEC 19" 42U Network Cabinet – 800 x 800mm is a high-capacity floor-standing rack designed to house and organise professional network, server, fibre and communications equipment. Offering a standard 19-inch mounting format, 42U rack capacity and a maximum load of 800kg, the cabinet provides a robust solution for demanding data centre, server room and enterprise network installations. With overall dimensions of 800 x 800 x 1984mm, the cabinet provides additional width for equipment installation and cable management while maintaining an 800mm depth. Four reinforced uprights provide increased stability for compatible rack-mounted equipment, supporting structured and high-density infrastructure deployments.

The cabinet features perforated front and rear doors, allowing airflow through installed equipment and supporting ventilation within the rack. This configuration is particularly beneficial when housing active network and server equipment that generates heat during operation. Lockable side panels provide convenient access for installation and maintenance while helping secure equipment once the cabinet is in service. Four included levelling feet allow the cabinet to be adjusted for stable positioning on the installation surface. Finished in professional RAL 9005 black, the cabinet is rated to IP20 and supplied with a screw and grounding kit for professional installation.

Key Features:

• Professional UPTEC 42U floor-standing network cabinet

• Standard 19-inch rack mounting format

• 800 x 800 x 1984mm overall dimensions

• High maximum load capacity of 800kg

• Perforated front door for improved equipment airflow

• Perforated rear door for through-cabinet ventilation

• Four reinforced uprights for increased stability

• Lockable side panels with clips and lock

• Four levelling feet for installation adjustment

• Screw and grounding kit included

Technical Specifications:

• Brand: UPTEC

• Product Type: Network Cabinet / Rack

• Rack Format: 19"

• Rack Capacity: 42U

• Dimensions: 800 x 800 x 1984mm

• Width: 800mm

• Depth: 800mm

• Height: 1984mm

• Maximum Load Capacity: 800kg

• Front Door: Perforated

• Rear Door: Perforated

• Uprights: 4 reinforced uprights

• Side Panels: Lockable with clips and lock

• Levelling: 4 levelling feet included

• IP Rating: IP20

• Protection: Solid objects greater than 12mm

• Colour: Black

• RAL Colour: RAL 9005

• Screw Kit: Included

• Grounding Kit: Included

• Installation Type: Floor Standing

Applications:

• Data centres

• Server rooms

• Enterprise networks

• Telecom infrastructure

• Network switch installations

• Server installations

• Structured cabling systems

• Fibre optic infrastructure

• Communications rooms

• High-density network equipment installations
