Optimized for high-performance environments, this shielded Cat8 S/FTP AWG22 network cable offers exceptional performance for very high-speed network installations, up to 40 Gbps. This Cat8 RJ45 cable is perfectly suited to:
- 25/40GBASE-T Ethernet networks
- Critical LAN installations and building backbones
- Cabling-dense or interference-prone environments
- Server rooms and data centers
Features:
- Category 8 (Cat.8): supports frequencies up to 2000 MHz for ultra-fast transmission
- AWG22 conductors: better conductivity and performance stability
- S/FTP shielding: each pair is shielded by an individual aluminum foil, supplemented by an overall tinned copper braid - for excellent protection against electromagnetic interference (EMI)
- LSZH sheath (Low Smoke Zero Halogen): limits smoke and toxic gas emissions in case of fire, ideal for confined environments and ERP
- Euroclass CPR: Dca: compliant with European fire reaction standards
- Operating temperature: from -20 °C to +75 °C - for a wide range of uses
- Characteristic impedance: 122.2 Ω at 1 MHz / 131.6 Ω at 1000 MHz - for stable transmission across the entire bandwidth
- Conductor DC resistance: 7.0 Ω/100m @ 20°C
- Insulation resistance: > 5000 MΩ.km
