MicroDucts LSHF Ribbed – Regular – 7x5/3.5mm – Natural Milk White
The MicroDucts LSHF Ribbed – Regular – 7x5/3.5mm – Natural Milk White solution is engineered for indoor fibre deployments requiring stringent safety and fire performance standards. This 7-way bundled configuration offers a compact and scalable ducting system that supports future-ready fibre networks in buildings, data centres, and public transport infrastructure.
Each of the 7 MicroDucts is made from Low Smoke Halogen Free (LSHF) materials and features a ribbed inner wall for added mechanical stability and cable management. The ducts are tested to European fire safety standards, including EN 13501-1, offering low flame spread and smoke emission, making them ideal for environments where human safety and equipment protection are critical.
Whether used for FTTH, FTTB, LAN or building backbone applications, this solution ensures seamless cable installation, efficient fibre jetting, and long-term durability.
Key Features:
- 7x 5/3.5mm MicroDucts bundled for high-density indoor installation
- Ribbed internal surface enhances structural integrity and routing control
- Manufactured from halogen-free, fire-retardant LSHF material
- Natural milk white colour for easy ID and aesthetic integration
- Fire tested to EN 13501-1 for safe indoor use
- Compliant with EN 50642 halogen-free standards
- Marked to EN IEC 61386-22:2021, verified by VDE (Germany)
- Designed for indoor FTTH, LANs, data centres, and transport environments
- Maintains an ideal fibre fill ratio of 50%–75%
Technical Specifications:
- Configuration: 7 MicroDucts (5mm OD / 3.5mm ID)
- Material: LSHF (Low Smoke Halogen Free)
- Internal Wall Type: Ribbed
- Outer Colour: Natural Milk White
- Fire Rating: B-s2, d0 or C-s2, d2 (based on installation)
- Halogen-Free Compliance: EN 50642
- Standard Markings: EN IEC 61386-22:2021, VDE certified
- Application Areas: FTTH, FTTB, LANs, Data Centres, Transit Hubs, Indoor Backbone
- Fill Ratio Guidance: Minimum 50%, Maximum 75%
|
