CAT6A Patchcord – U/UTP – RJ45 to RJ45 – AWG28 – Small OD – Black – 2.7m

CAT6A Patchcord – U/UTP – RJ45 to RJ45 – AWG28 – Small OD – Black – 2.7m

The CAT6A U/UTP RJ45 to RJ45 Patchcord – 2.7m is a slim-profile network patch cable featuring Patchsee and Patchclip technologies for fast and straightforward cable identification. Compatible with Pro-Patchlight light injectors, the integrated light identification system helps technicians quickly trace individual connections, particularly within high-density network environments.

Featuring AWG28 tinned copper conductors in a four-pair U/UTP configuration, the patchcord supports network applications up to 10 Gbit/s. Its compact 3.8mm overall diameter helps reduce cable congestion within densely populated racks and cabinets, supporting improved accessibility and cable management.

An integrated optical waveguide consisting of two 0.5mm plastic optical fibres enables light-based cable identification. The slim sleeve is aligned with the RJ45 connector, helping maximise connection density and simplify access around patch panels, switches and other network equipment.

Finished with a black PVC sheath, the 2.7m patchcord includes reference and length markings on the sleeve. Its length provides flexible routing between network equipment while helping maintain a neat and organised structured cabling installation.

Key Features:

• CAT6A U/UTP network patchcord

• RJ45 to RJ45 connectivity

• 2.7 metre cable length

• AWG28 tinned copper conductors

• Slim 3.8mm overall cable diameter

• Supports applications up to 10 Gbit/s

• Patchsee and Patchclip identification technologies

• Compatible with Pro-Patchlight light injectors

• 16 Patchclip identification colours available

• Integrated plastic optical waveguide

• Slim RJ45-aligned sleeve for high-density patching

• Black PVC outer sheath

• Reference and cable length marked on sleeve

• 100 Ohm impedance

• 11 lengths available from 0.6m to 4.9m

• Compatible with Category 5e, 6 and 6A applications

Technical Specifications:

• Product Type: Network Patchcord

• Category: CAT6A

• Cable Type: U/UTP

• Connector A: RJ45

• Connector B: RJ45

• Length: 2.7m

• Colour: Black

• Conductor Size: AWG28

• Conductor Material: Tinned Copper

• Conductor Construction: 7 / 0.124 ± 0.003mm

• Number of Pairs: 4

• Overall Diameter: 3.8mm

• Bending Radius: 11.4mm

• Impedance: 100 Ohm

• Insulation: High-Density Polyethylene

• Optical Waveguide: 2 x 0.5mm Plastic Optical Fibres

• Outer Sheath: PVC

• Maximum Application Speed: Up to 10 Gbit/s

• Standards: TIA/EIA-568.2-D, ISO/IEC 11801-2:2017

Applications:

• Data centres

• High-density network racks

• Server cabinets

• Patch panels

• Network switches

• Structured cabling systems

• Telecoms infrastructure

• Network equipment interconnections

• Cable identification and tracing

• Professional network installations
