CAT6A Patchcord – U/UTP – RJ45 to RJ45 – AWG28 – Small OD – Black – 1.5m

CAT6A Patchcord – U/UTP – RJ45 to RJ45 – AWG28 – Small OD – Black – 1.5m

The CAT6A U/UTP RJ45 to RJ45 Patchcord – 1.5m is a slim-profile network patch cable designed for high-density structured cabling environments. Combining Patchsee and Patchclip technologies, it provides a convenient method of identifying individual network connections, helping simplify cable tracing, patching and maintenance.

The patchcord features AWG28 tinned copper conductors in a four-pair U/UTP configuration and supports network applications up to 10 Gbit/s. Its compact 3.8mm overall diameter helps reduce cable congestion compared with conventional patchcords, making it particularly suitable for densely populated network racks and cabinets.

An integrated optical waveguide consisting of two 0.5mm plastic optical fibres supports Patchsee light-based cable identification. Combined with the slim sleeve aligned with the RJ45 connector, this design improves accessibility around high-density patch panels and network equipment.

Finished with a black PVC sheath, the 1.5m patchcord features reference and length markings on the sleeve for easier identification. It is designed for professional data centre, telecoms and structured cabling installations requiring high-performance connectivity with improved cable management.

Key Features:

• CAT6A U/UTP network patchcord

• RJ45 to RJ45 connectivity

• 1.5 metre cable length

• AWG28 tinned copper conductors

• Slim 3.8mm overall diameter

• Supports applications up to 10 Gbit/s

• Patchsee and Patchclip identification technologies

• 16 Patchclip identification colours available

• Integrated plastic optical waveguide

• Slim RJ45-aligned sleeve for higher-density patching

• Black PVC outer sheath

• Reference and cable length marked on sleeve

• 100 Ohm impedance

• Designed for high-density network environments

• Compatible with Category 5e, 6 and 6A applications

Technical Specifications:

• Product Type: Network Patchcord

• Category: CAT6A

• Cable Type: U/UTP

• Connector A: RJ45

• Connector B: RJ45

• Length: 1.5m

• Colour: Black

• Conductor Size: AWG28

• Conductor Material: Tinned Copper

• Conductor Construction: 7 / 0.124 ± 0.003mm

• Number of Pairs: 4

• Overall Diameter: 3.8mm

• Bending Radius: 11.4mm

• Impedance: 100 Ohm

• Insulation: High-Density Polyethylene

• Optical Waveguide: 2 x 0.5mm Plastic Optical Fibres

• Outer Sheath: PVC

• Maximum Application Speed: Up to 10 Gbit/s

• Standards: TIA/EIA-568.2-D, ISO/IEC 11801-2:2017

Applications:

• Data centres

• High-density network racks

• Server cabinets

• Patch panels

• Network switches

• Structured cabling systems

• Telecoms infrastructure

• Network equipment interconnections

• Cable identification and tracing

• Professional network installations
