Blade Terminal – Red – 18mm Blade – Entry 0.5-1.5mm – Pack of 100
The Blade Terminal – Red – 18mm Blade – Entry 0.5-1.5mm – Pack of 100 is a high-quality pre-insulated crimp terminal designed to provide secure and reliable electrical connections in industrial, commercial and automotive applications.
Manufactured from oxygen-free high conductivity copper, each terminal is electro-tin plated to provide excellent corrosion resistance and long-lasting electrical performance. The red PVC insulation identifies compatibility with 0.5-1.5mm² conductors and offers reliable insulation with a maximum operating temperature of 75°C.
Featuring an 18mm blade, the terminal is suitable for a wide range of switchgear, control panels and electrical equipment where quick, secure blade connections are required. Supplied in a pack of 100, these terminals are ideal for professional installers and maintenance engineers.
Key Features:
-
Pre-insulated blade terminal
-
18mm blade width
-
Suitable for 0.5-1.5mm² cable
-
Red PVC insulation
-
Manufactured from oxygen-free high conductivity copper
-
Electro-tin plated for corrosion resistance
-
Maximum operating temperature of 75°C
-
UKCA approved
-
Reliable crimp connection
-
Pack of 100
Technical Specifications:
-
Product Type: Blade Terminal
-
Blade Width: 18mm
-
Cable Entry: 0.5-1.5mm²
-
Insulation Colour: Red
-
Quantity: 100
-
Terminal Material: Oxygen-Free High Conductivity Copper
-
Insulation Material: PVC
-
Finish: Electro-Tin Plated
-
Maximum Operating Temperature: 75°C
-
UKCA Approved: Yes
Applications:
-
Electrical installations
-
Control panels
-
Switchgear
-
Industrial automation
-
Telecommunications equipment
-
Automotive wiring
-
Marine electrical systems
-
Electrical maintenance
-
Power distribution
-
General cable termination
