19" Fibre Patch Panel – ST/ST – 16 Way – 1U

19" Fibre Patch Panel – ST/ST – 16 Way – 1U

The 19" Fibre Patch Panel – ST/ST – 16 Way – 1U is a high-density fibre optic termination panel designed to provide professional fibre management within standard 19-inch network cabinets and server racks.

Supplied with 16 ST/ST adaptors, this compact 1U fibre patch panel delivers an economical solution for terminating and organising fibre optic cables without compromising valuable rack space. The sliding tray is secured by two simple-to-operate plastic latches and can be lowered to either 45° for installation or 10° for maintenance, providing excellent access to fibre connections while the panel remains installed in the rack.

Designed with professional installers in mind, the panel features recessed adaptors for improved fibre management, rear cable entry options, integrated identification labels, concealed fixings for a clean appearance and mounting points for universal front cable management. The innovative Easy Slot design also allows direct attachment of pre-terminated FastFibre manifolds and enables glands or trays to be installed and removed while the panel remains mounted.

Manufactured from 1.2mm cold rolled steel with a durable electrostatic powder-coated black finish (RAL 9004), the panel is suitable for data centres, telecommunications rooms and enterprise fibre network installations.

Key Features:

• 19-inch rack-mounted fibre patch panel

• 1U high-density design

• 16-way ST/ST fibre connectivity

• Sliding tray with 45° and 10° working positions

• Recessed adaptors for improved fibre management

• Rear cable entry options

• Easy Slot for FastFibre manifold installation

• Universal front cable management fixing points

• High-quality powder-coated steel construction

• Concealed fixings with integrated identification labels

Technical Specifications:

• Product Type: Fibre Patch Panel

• Rack Width: 19-inch

• Rack Height: 1U

• Fibre Capacity: 16 Way ST/ST

• Adaptor Type: ST (24 Fibre)

• Dimensions (H × W × D): 44.4 × 482 × 205mm

• Net Weight: 2.4kg

• Packaged Weight: 3kg

• Packaged Dimensions: 55 × 530 × 260mm

• IP Rating: IP20

• Mounting Adjustment Range: 50mm

• Cable Entry:

  • 20mm²

  • 25mm²

• Easy Slot: 2

• Material: 1.2mm Cold Rolled Steel

• Finish: Electrostatic Powder Coating

• Colour: Black (RAL 9004)

• Operating Temperature: -40°C to +60°C

Compliance

• RoHS2

• REACH / SVHC

• TIA/EIA 568A-C

• ISO/IEC 11801

• EN 50173

• IEC 60304

• IEC 61754

• EN 297-1

Applications:

• Data centres

• Telecommunications networks

• Fibre optic patching

• Enterprise LAN infrastructure

• Server rooms

• Optical distribution frames

• FTTH installations

• Campus networks

• Network cabinets

• Fibre backbone management
