Designed for long-distance network infrastructures, the 12-core single-mode OS2 fiber optic cable is ideal for backbone applications, metropolitan area networks (MAN), and inter-building connections. Thanks to its tight 900 µm structure and black LSZH sheath, this cable ensures a secure installation that complies with fire standards, while also guaranteeing exceptional transmission performance over long distances. It features Rapid Strip technology for easy stripping, and can be installed indoors or outdoors due to its waterproof design. This single-mode OS2 cable is designed to deliver high speed, low attenuation, and excellent longevity. Its robustness and flexibility make it a preferred choice for demanding installations requiring absolute reliability.
Technical characteristics:
- Fiber type: Single-mode OS2 – 9/125 µm
- Number of fibers: 12 cores
- Structure: Tight 900 µm with RS900 technology (Rapid Strip)
- Outer sheath: Black LSZH (Low Smoke Zero Halogen), halogen-free, low smoke emission
- Outer diameter: 7.5 mm
- Weight: 49 kg/km
- Maximum tensile strength: 800 N
- Crush resistance: 200 N/cm
- Minimum bending radius: 10 times the cable diameter
- Operating temperature: -30°C to +70°C
- Installation temperature: -5°C to +50°C
- Storage temperature: -40°C to +70°C
- Standards and certifications:
- Euroclass Dca-s1,d1,a2
- EN 50173-1, ISO/IEC 11801, IEC 60794-2-20
- Fire resistance: IEC 60332-1, EN 50399
- Low emission of acid gases: IEC 60754-2
- Packaging: 2100-meter reel
