Optimized for high-performance networks, the 24-strand OM3 fiber optic cable is the ideal solution for LAN infrastructures, data centers, and backbone installations requiring high speed and reliability. With its tight 900µm structure and black LSZH outer sheath (Low Smoke Zero Halogen), this cable ensures excellent fire protection while providing secure installation in residential, commercial, or industrial environments. Its waterproof design allows for indoor and outdoor installation, and the Rapid Strip technology greatly simplifies fiber stripping.
Designed for high bandwidth, this OM3 cable supports transmissions up to 10 Gbit/s over long distances, while offering great installation flexibility. It is delivered on reels of 2100 meters, making it ideal for large-scale projects.
Technical Specifications:
- Fiber Type: Multimode OM3 - 50/125 µm
- Number of Fibers: 24 strands
- Structure: Tight 900 µm with Rapid Strip RS 900 technology
- Outer Sheath: Black LSZH, for low smoke emission without halogens
- Cable Diameter: 9.8 mm
- Weight: 89 kg/km
- Maximum Tension: 1600 N
- Crush Resistance: 200 N/cm
- Minimum Bending Radius: 10 times the diameter
- Temperatures:
- Use: -30°C to +70°C
- Installation: -5°C to +50°C
- Storage: -40°C to +70°C
