Designed for long-distance network infrastructures, the OS2 single-mode 24-fiber optical cable is ideal for backbone applications, metropolitan area networks (MANs), and inter-building connections. With its tight-buffered 900 µm structure and black LSZH sheath, this cable ensures secure installation compliant with fire standards while guaranteeing exceptional transmission performance over long distances. It features Rapid Strip technology for easy stripping and can be installed indoors or outdoors thanks to its waterproof design. This OS2 single-mode cable is designed to ensure high speed, low attenuation, and excellent durability. Its robustness and flexibility make it an ideal choice for demanding installations requiring absolute reliability.
Technical specifications:
- Fiber Type: Single-mode OS2 – 9/125 µm
- Number of Fibers: 24 fibers
- Structure: Tight-Buffered 900 µm with RS900 (Rapid Strip) technology
- Outer Sheath: Black LSZH (Low Smoke Zero Halogen), halogen-free, low smoke emission
- Outer Diameter: 9.8 mm
- Weight: 89 kg/km
- Maximum Traction: 1600 N
- Crush Resistance: 200 N/cm
- Minimum Bend Radius: 10 times the cable diameter
- Operating Temperature: -30°C to +70°C
- Installation Temperature: -5°C to +50°C
- Storage Temperature: -40°C to +70°C
- Standards and Certifications:
- Euroclass Dca-s1,d1,a2
- EN 50173-1, ISO/IEC 11801, IEC 60794-2-20
- Fire Resistance: IEC 60332-1, EN 50399
- Low Acid Gas Emission: IEC 60754-2
- Packaging: 2100-meter drum
