The 12 strands 250µm OM3 free structure cable is an ideal solution for high-speed installations, such as local area networks (LAN), data centers, and multimode optical fiber cabling applications. Designed with OM3 fibers, this cable supports high transmission speeds and long distances while providing high reliability. Its 250µm free structure ensures optimal flexibility for easy installation and splicing. The cable is also equipped with an LSZH (Low Smoke Zero Halogen) sheath, offering increased safety in case of fire due to its low smoke emission and absence of halogens. It is perfectly suited for indoor installations in security-sensitive environments.
This cable is designed for multimode installations with speeds up to 10 Gbit/s, making it ideal for modern network applications and high-performance infrastructures. Its robust design and compliance with the strictest standards make it a reliable choice for a wide range of applications.
Technical specifications:
- Fiber Type: Multimode OM3 - 50/125µm
- Number of Strands: 12 strands
- Structure: Free structure 250µm
- Outer Sheath: LSZH (Low Smoke Zero Halogen)
- Outer Diameter: 6mm
- Weight: 40 kg/km
- Maximum Tensile Strength: 1500 N
- Crush Resistance: 150 N/cm
- Minimum Bending Radius: 10 times the cable diameter
- Operating Temperature: -20°C to +70°C
- Installation Temperature: -5°C to +50°C
- Storage Temperature: -40°C to +70°C
- Standards and Certifications:
- Euroclass Dca-s1,d1,a2
- EN 50173-1, ISO/IEC 11801
- Fire Resistance: IEC 60332-1, EN 50399
- Low Emission of Acid Gases: IEC 60754-2
