PTO ONE Plus ID 2F with SC/APC Adaptor & Pigtail – Pack of 20

The PTO ONE Plus ID 2F is a compact and discreet pre-terminated fibre optic outlet, ideal for FTTH (Fibre to the Home) deployments. Supplied with SC/APC adaptors and pigtails, this termination box allows quick splicing and secure, low-loss connections in indoor environments.

Designed with a clear identification window, multiple cable entries, and internal fibre management, it supports flexible installations while maintaining protection and bend radius control. Its robust ABS-PC housing ensures impact resistance and compliance with strict IEC standards.

Key Features:

• Compact, neat, and discreet wall-mount design

• Supplied with SC/APC adaptors and pigtails

• Enhanced mechanical protection with internal slack storage

• Bending radius control >15mm for safe fibre handling

• Multiple cable entries for installation flexibility

• Optimised for quick mounting and easy re-entry

• Can be used as a transition box

• Transparent ID window for QR or label insertion

Technical Specification:

• Capacity: 2 fibres (900μm)

• Optical Performance (IEC-61300-3-4): IL < 0.3dB / RL < -60dB

• Bending Radius: >15mm

• Tensile Strength: >5daN

• Protection Rating: IP40

• Impact Resistance: IK05

• Material: ABS-PC, UV protected

• Colour: White (RAL 9010)

• Mounting Plane: 60mm interaxe spacing

• Supplied in: Pack of 20 units
