Vane Anemometer – D02377
The D02377 Vane Anemometer is a compact, easy-to-use digital instrument designed for accurately measuring air velocity across a wide range of applications, including HVAC testing, ventilation checks, environmental monitoring, and onsite engineering work. Featuring a clear 4-digit LED display with backlight, it provides fast and reliable readings in multiple selectable units to suit different measurement standards.
With functions including flow area setting, max/min recording, auto power-off, and low battery indication, this anemometer offers practical usability for both field and workshop environments. The unit measures air speed in ft/min, km/h, mph, knots and m/s, ensuring flexibility for professional use.
Supplied with a protective carry case, the D02377 is lightweight, durable and ideal for engineers who require accurate airflow measurements on the move.
Key Features:
-
Measures air velocity across a wide multi-unit range
-
4-digit LED display with backlight for clear visibility
-
Flow area input for improved airflow calculations
-
Max/Min capture and auto power-off functions
-
Low battery indication for reliability
-
Supplied with carry case for transportation and protection
-
Requires 1 × 9V PP3 battery (not included)
Technical Specifications:
-
Air Velocity Range: 0.4m/s to 30m/s
-
ft/min: 80–5900 ft/min (±2%)
-
km/h: 1.4–108 km/h (±2%)
-
mph: 0.9–67 mph (±2%)
-
knots: 0.8–58 knots (±2%)
-
Operating Temperature: 0°C to 40°C
-
Dimensions: 165mm (H) × 85mm (W) × 38mm (D)
-
Battery: 1 × 9V PP3 (not supplied)
