Key Characteristics:
Article Number - 170381
Order Reference - M211-EU-UK-US
Total Quantity per Pack - 1 Piece(s) / Box
Application(s) - Data and telecommunications labelling, Electrical labelling, General identification, Lean and 5S labelling, Warehouse marking, Wire and cable labelling
Quantity - 1
Trade Name - M211
Country of Origin - MY
Dimensions:
Width (mm) - 137.16 mm
Height (mm) - 101.60 mm
Depth (mm) - 66.04 mm
Weight (kg) - 0.54 kg
Min. Label Width (mm) - 6.40 mm
Material Characteristics:
Material Supported - Heat-shrink Polyolefin, Nylon Cloth, Paper, Polyester, Polypropylene, Self-laminating Polyester, Self-laminating Vinyl, Vinyl
Colour - Yellow, Black
Product Features:
Battery mAh Rating - 1200 mAh
Bar Code Type - Code 128, Code 128A, Code 128B, Code 128C, Code 39, Code 39 Full ASCII, Code 93, Code 93 Full ASCII, EAN-13, EAN-13 Extension 2, EAN-13 Extension 5, EAN-8, EAN-8 Extension 2, EAN-8 Extension 5, GS1-128, HIBC, Interleaved 2 of 5, JAN-13, JAN-8, UPC-A, UPC-E
Auto Shut Off - User Configurable, Yes
Battery Type - Internal, not removable, Lithium-ion Battery
Built-in Symbols - Dependant on software
Language Support - Bahasa (Indonesian), Bahasa Malay, Bulgarian, Chinese (Traditional & Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Norwegian (Bokmål), Polish, Portuguese, Romanian, Russian, Slovak, Slovenian, Spanish (universal), Swedish, Thai, Turkish, Vietnamese
Calibration - Automated through Smart Cell
Connectivity Options - Bluetooth® 5 Low Energy (class II)
Custom Labels Available - No
Cutter - Auto Cutter with label retention
Display Type - None
How is Battery Shipped - Shipped installed in equipment
Interface Type - Mobile device
Internal Memory Capacity - Memory via connected mobile device
Keyboard Type - None
Operating Humidity Range - 20%-90% (non-condensing)
Operating Temperature - 4°C - 43°C
Stand Alone Printing - Mobile device connected
PC Connectivity - No
Power Source - AC Adaptor Rechargeable Battery USB
Power Supply Voltage - 110 - 240 V
Printing Wizards - Breaker Box, Flags, General, Patch Panel, Pipe Marker, Safety, Sleeves, Terminal Block, Wire Wrap
Recharge Time - 4 hours
Shipped with Battery - Yes
Storage Humidity - 10%-90% (non-condensing)
Storage Temperature - -18°C - 43°C
Printing Specifications:
Print Technology - Thermal Transfer
Print Speed (mm/sec) - 15.24 mm/s
Printing Functions - Auto Format, Autosizing, Bold, Condensed, Date/Time Stamp, Expand, Fixed Length, Frame Feature, Italics, Justification, Multi-copy, Outline, Reverse, Rotate, Serialisation, Underline, Vertical
Colour Capacity - Monocolour
Resolution (dpi) - 203 dpi
Display Resolution - N/A
Max. Label Width (mm) - 19.05 mm
Max. Liner Width (mm) - 22.23 mm
Recommended Usage per Day - 100
Max. Print Width (mm) - 15.75 mm
Max. Print Length (mm) - 914.40 mm
Text Size (pt) - 4 to 150 pt
Font Styles - Determined by software
Symbol Categories - Determined by software
Number of Stock Parts - 90+ standard parts
On Screen Indicators - Battery Life, Bluetooth Status, Error Messaging
Device Indicators - Bluetooth indicating lights: pulsing blue = broadcasting signal; solid blue = device connected or paired, Error indicating lights: pulsing orange = error, Power indicating lights: solid green = 51-100% battery life; solid orange = 21-50% battery life; solid red = 11-20% battery life; flashing red = 1-10% battery life; flashing green = charging
Print Rotation - Yes
Drop Test - Resistant to 1.8-metre drops, Resistant to 115 kg crushes, Resistant to military-grade shocks (MIL-STD-810G)
Serialisation - Multiple & Linked
Smart Cell - Yes
Compatibility:
Continuous vs Die Cut Labels - Continuous and Die-Cut
Software Compatibility - Express Labels Mobile App
Phones & Tablets Supported - Android devices with Android OS 5+, iPhone 5S or newer with IOS 10+
B- Numbers supported - B-342, B-403, B-414, B-423, B-427, B-430, B-461, B-488, B-499, B-581, B-595, B-7425
Compatible Media - M21-
What's Included:
Includes - This printer ships in a carton pack with an M21-750-499 label cartridge, AC power cord with EU, UK and US plugs and Quick Start Guide
Warranty - 2 years
