Key Characteristics:
| |
Article Number |
196454 |
| |
Order Reference |
BMP61-QWERTY-UK-W |
| |
Total Qty per Pack |
1 Piece(s) / Pack |
| |
Application(s) |
Asset tracking, Circuit board labelling, Data and telecommunications labelling, Electrical labelling, Facility identification, General identification, Safety identification, Wire and cable labelling |
| |
Quantity |
1 |
| |
Brand |
Brady® |
| |
Trade Name |
BMP®61 |
| |
Country of Origin |
MY |
Dimensions:
| |
Size - Width (mm) |
107.19 mm |
| |
Size - Height (mm) |
328.42 mm |
| |
Size - Depth (mm) |
106.42 mm |
| |
Weight (kg) |
1.41 kg |
| |
Display Size |
71.12 mm |
| |
Minimum Label Height (mm) |
5.99 mm |
| |
Min. Label Width (mm) |
6.40 mm |
| |
Dimensions |
107.19 mm (W) x 328.42 mm (H) x 106.42 mm (D) |
Material Characteristics:
| |
Materials Supported |
FreezerBondz™ Polyester, Heat-shrink Polyolefin, High-Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Metallised Polyester, Metallised Polyester with Polyester Overlaminate, Nylon Cloth, Paper, Polyester, Polyethylene, Polyethylene Foam Laminate Polyester, Polyimide, Polyolefin, Polypropylene, Polyvinylfluoride, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-evident Metallised Polyester, Tamper-evident Polyester, Tamper-resistant Metallised Vinyl, Tamper-resistant Vinyl, Vinyl, Vinyl Cloth |
| |
Colour |
Yellow, Grey |
Product Features:
| |
Battery mAh Rating |
1200 mAh |
| |
Bar Code Type |
Code 128, Code 39, More through Brady WorkStation |
| |
Auto Shut Off |
User Configurable |
| |
Battery Type |
NiMH Battery, Rechargeable Battery |
| |
Battery Weight |
0.56 lb |
| |
Built-in Symbols |
450 |
| |
Language Support |
Bulgarian, Croatian, Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Hungarian, Italian, Norwegian (Bokmål), Polish, Portuguese, Romanian, Russian, Slovak, Slovenian, Spanish, Swedish, Turkish |
| |
Calibration |
Automated through Smart Cell |
| |
Connectivity Options |
Cabled, Standalone Use, USB 2.0, USB Host |
| |
Bar Code Type 3 |
Yes |
| |
Custom Labels Available |
Yes |
| |
Cutter |
Between labels or at end of print job, Manual cut |
| |
Display Type |
Colour Touchscreen, LCD backlit graphics display |
| |
Interface Type |
Full QWERTY Keyboard, PC, Touchscreen |
| |
Internal Memory Capacity |
512 MB RAM, 256 MB Flash |
| |
Keyboard Type |
QWERTY |
| |
Label Dimensions |
Various sizes from 6.4mm to 50.8mm |
| |
Operating Humidity Range |
10%-90% (non-condensing) |
| |
Operating Temperature |
5°C - 49°C |
| |
Stand Alone Printing |
Stand-alone & Peripheral |
| |
PC Connectivity |
Yes |
| |
Power Source |
AC Adaptor, Rechargeable Battery |
| |
Power Supply Voltage |
110 - 240 V |
| |
Printing Wizards |
Flags, Patch Panel, Terminal Block, Wire Wrap |
| |
Recharge Time |
4 hours |
| |
Shipped With Battery |
Yes |
| |
Storage humidity |
10%-90% (non-condensing) |
| |
Storage Temperature |
-40°C - 70°C |
Printing Specifications:
| |
Print Technology |
Thermal Transfer |
| |
Print Speed (mm/sec) |
33.80 mm/s |
| |
Printing Functions |
Auto Format, Banner, Date/Time Stamp, Fixed Length, Justification, List Function, Mirror, Multi-copy, Print Preview, Reverse, Rotate, Serialisation, Vertical |
| |
Colour Capability |
Monocolour |
| |
Resolution (dpi) |
300 dpi |
| |
Display Resolution |
320 x 240 pixels |
| |
Max. Label Width (mm) |
50.80 mm |
| |
Max. Liner Width (mm) |
57.00 mm |
| |
Recommended Usage per Day |
750 |
| |
Max. Print Width (mm) |
50.80 mm |
| |
Max. Print Length (mm) |
1016.00 mm |
| |
Text Sizes (pt) |
4 - 170 pt |
| |
Font Styles |
Brady Alpine, Brady Fixed Width |
| |
Symbol Categories |
Arrows, Datacom, Electrical, Exit, Fire Safety, First Aid, GHS/CLP, Greek, Home Electrical, HSID, International, Laboratory, Mandatory, Miscellaneous, Packaging, Personal Protective Equipment, Prohibition, Public Information, Safety, Warning, WHIMIS |
| |
Multi-Line Print |
Yes |
| |
Number of Stock Parts |
800+ standard parts |
| |
On Screen Indicators |
Battery Life, Ribbon and label part number recognition, Ribbon Remaining, Supply Remaining |
| |
Print Rotation |
Yes |
| |
Drop Test |
Resistant to 1.2-metre drops |
| |
Serialisation |
Multiple & Linked |
| |
Smart Cell |
Yes |
Compatibility:
| |
Continuous vs Die Cut Labels |
Continuous and Die-cut |
| |
Software Compatibility |
Brady Workstation, Express Labels Mobile App |
| |
B- Numbers supported |
B-109, B-145, B-321, B-342, B-344, B-345, B-362, B-390, B-412, B-422, B-423, B-424, B-425, B-427, B-428, B-430, B-432, B-435, B-437, B-439, B-459, B-461, B-473, B-483, B-486, B-488, B-489, B-490, B-498, B-499, B-642, B-717, B-718, B-719, B-724, B-727, B-7351, B-7546, B-7551, B-7576, B-7593, B-7597, B-7598, B-7599, B-7643, B-7696, B-7697, B-966, B-966B
|
| |
Compatible Media |
BM61-, BM61D-, BM61E-, BM71-, BM71C-, BM71D-, BM71R-, BPTDS-, BPTL-, M61-, M61C-, M61EP-, PSFR-, PSHT-, PSPT-, PTDS-, PTDSU-, PTL-, PTLCM-, PTLEP-, PTLFP-, PTLFT-, PTLRDS-, PTLSL-, PTLTB-, PTLTL-, PTPSL-, PTS- |
| |
Min. Label Length (mm) |
5.99 mm |
| |
Min. Liner Width (mm) |
20.62 mm |
What's Included:
| |
Includes |
This printer ships in a hard case holding a USB cable, a quick start guide, a battery pack, an AC Adapter with UK power cord, Brady Workstation Basic Suite, a driver CD, a product CD, a roll of PTL-19-423 and an M61-R6010 ribbon |
| |
Warranty |
2 years |
Compliance:
| |
UNSPSC |
45101520 |
| |
RoHS Compliance Status |
Compliant with Directive 2011/65/EU and 2015/863 |
| |
REACH SVHC Status |
Part contains an SVHC |
| |
REACH Candidate List Date |
08 July 2021 |
| |
Approval/Compliance |
CE 2014/53/EU RED, 2014/35/EU LVD, 2014/30/EU EMCD, 2011/65/EU, 2015/863/EU; UL 60950-1, 2nd Edition; EN \ IEC 60950-1:2006 + A11:2009 + A1:2010 + A12:2011+ A2:2013; WEEE; RoHS2; ICASA |
|
