Key Characteristics:
|
Article Number |
196773 |
|
Order Reference |
BM71-15x75-7643-YL |
|
Total Qty per Pack |
250 Tag(s) / Roll |
|
QTY. per Row |
1 |
|
Application(s) |
Data and telecommunications labelling, Wire and cable labelling |
|
Quantity |
250 |
|
Voice/Data Application |
Communication Cables |
|
Brand |
Brady® |
|
Qty per Roll |
250 |
|
Ribbon Series |
R6000HF |
|
Country of Origin |
BE |
Dimensions:
|
Size - Width (mm) |
15.00 mm |
|
Size - Height (mm) |
75.00 mm |
|
Core - Diameter (mm) |
76.20 mm |
|
Hole Diameter (mm) |
5.50 x 2.50 mm |
|
Printable Area Dimensions |
15.00 mm W x 55.00 mm H |
|
Printable Area - Height (mm) |
55.00 mm |
|
Printable Area - Width (mm) |
15.00 mm |
|
Vertical Repeat (mm) |
80.43 mm |
|
Web Width (mm) |
26.97 mm |
|
Dimensions |
15.00 mm (W) x 75.00 mm (H) |
Material Characteristics:
|
Brady Material No. |
B-7643 (View Technical Data Sheet) |
|
Brady Material Type |
Thermoplastic Polyether Polyurethane |
|
Material Properties |
Zero-halogen |
|
Thickness (mm) |
0.45 mm |
|
Colour |
Yellow |
|
Max. Service Temp. °C |
90 °C |
|
Min. Service Temp. °C |
-40 °C |
|
Finish |
Matt |
|
Resistance Properties |
Abrasion-resistant, Chemical-resistant, Humidity-resistant |
Product Features:
|
# of Holes |
4 |
|
Shape |
Rectangle |
|
Hole Shape |
Oval |
Printing Specifications:
|
Print Technology |
Thermal Transfer |
|
Max. Characters per Line |
51 |
|
Smart Cell |
Yes |
Compatibility:
|
Printer Compatibility |
BMP61, BMP71, M611 |
Compliance:
|
UNSPSC |
55121503 |
|
RoHS Compliance Status |
Compliant with Directive 2011/65/EU and 2015/863 |
|
REACH SVHC Status |
Part does not contain an SVHC |
|
REACH Candidate List Date |
16 July 2019 |
|
Approval/Compliance |
Halogen free per IEC 61249-2-21 (2003-11), Adherence: SAE-AS81531-1998, Flame retardant: MIL-STD-202G |
|
